Astreea® Charger Double with Display and Cables

The Astreea® Charger is a sleek, high-performance charging station available with single or dual 22 kW modules. With cutting-edge technology housed in an ultra-compact diameter of just 114 mm (4.48 in), it is engineered for modular flexibility and minimal footprint. This innovative design makes the Astreea® Charger the perfect solution for public parking areas, hotels, office buildings, and retail centers, seamlessly integrating advanced charging capabilities into any environment.

Free shipping in Europe

Comes with a 2-year guarantee

€ 2,720.00

without VAT

Output Connection
Type 2
Maximum Output
2 x 22KW
Maximum Input
32A or 2x 32A
Input Voltage
3Ph+N+PE 400V
In accordance with
IEC 61851-1:2019 IEC 61851-21.2:2021 European Low Voltage Directive 2014/35/EU European RED Directive 2014/53/EU IEC 62196, Type 2 EN 60529 MID Certification Eichrecht Certification (Display Version) IK10
Operating Temperature
-30°C to +60°C (-22 °F to +140 °F)
Humidity
5% - 95% non-condensing
Protection Class
RCBO type A 30mA, 50Hz, 40A
Protocols
OCPP 1.6 and 2.0 NFC MODBUS TCP BacNet MQTT WiFi Bluetooth Ethernet
Software
Mobile Application iOS and Android
Dimensions
1171 mm x Ø114 mm (46.10 in x Ø4.48 in)

Includes your device selected. An installation guide is provided. Packaged in one box. ⚠️ IMPORTANT WARNING Before installing the electric vehicle charger, it is MANDATORY to carefully read the installation manual provided. Incorrect installation may result in: Serious risk of electric shock Fire hazards due to improper wiring Damage to the equipment Voiding the product warranty Installation must be carried out only by authorized personnel, in compliance with all applicable legal and technical standards. Your safety is our priority.

View Installation Guide Video

Download Installation Guide PDF

See all products

Created for those who travel into the future.

Designed and manufactured entirely in the US and Europe.

Aerospace-level craftsmanship

Built by ARSAT®, a global aerospace engineering leader with over 30 years of expertise, Astreea® charging stations are crafted from premium stainless steel, designed to withstand demanding, high-traffic environments and harsh weather. Astreea® offers fast, safe charging wherever and whenever it’s needed.

New

Shock and tilt detection

Bespoke solutions for achieving business success

Astreea® Chargers incorporate adaptive load-balancing technology, dynamically adjusting the electrical supply in real-time to optimize performance based on pre-configured settings. This ensures efficient resource utilization and uninterrupted operation. Astreea® Chargers are designed to perform in extreme environments. Their robust construction shields internal components from moisture, dust, and temperature variations, ensuring seamless operation in temperatures ranging from -30°C to +60°C (-22°F to +140°F).

Installation Guide

No items found.

Cutting-edge connection

With the Astreea® app, easily manage all charging operations via an intuitive dashboard, available on both web and mobile devices. It provides full oversight of charging history, consumption, and payment options, ensuring efficient management. Astreea® Chargers offer advanced connectivity options, including NFC, Wi-Fi, Ethernet, and Bluetooth, allowing for seamless activation by simply holding your phone near the station to instantly start charging.

Our Store

Advanced technology at the core. Arm® Cortex® Processor.

The ultra-efficient 32-bit Arm® Cortex® microcontroller powers each 22 kW module, optimized for energy savings while protecting against AC, DC, and pulsating current leakage. Featuring smart power reduction at high temperatures and intelligent condensation prevention, this technology guarantees reliable and durable operation. Compatible with the OCPP Standard, the station can be connected to both national and international charging networks for maximum usability.
